Exterior Metal Framing System

Shop drawings were prepared for the exterior metal framing system supporting the facade of a commercial building. The scope included detailed layout drawings, member sizing, connection details, and anchorage to the primary structure. The system was designed to support cladding elements while ensuring compliance with applicable codes, wind load requirements, and coordination with other building systems.
